KOR
Traverse Type
FRANCIA series
Excellent performance take-out for any sized machines
  • facebook
  • twitter
DOWNLOAD
Product line
  • FRANCIA-306i(s)
  • FRANCIA-308i(s)
  • FRANCIA-509(s)
  • FRANCIA-509i(s)
  • FRANCIA-510(s)
  • FRANCIA-510i(s)
  • FRANCIA-809i(s)
  • FRANCIA-1013(s)
  • FRANCIA-1013i(s)
  • FRANCIA-1516(s)
  • FRANCIA-1516i(s)
  • FRANCIA-2018(s)
  • FRANCIA-2518(s)
  • FRANCIA-3020
  • FRANCIA-3520
  • FRANCIA-5025
Application field

  • Automotive

  • Packaging

  • PET-Preform

  • Micro & Precision

  • Home Appliance

  • Consumer Goods

  • Mobile

  • Medical

  • ETC

Common specifications
  • ▶I.M.M (ton)　 　　　50~3,000 (Horizontal I.M.M)

    ▶Traverse (mm)　　　1,000 / 1,400 / 1,600 / 2,000 / 2,300 / 2,500 / 3,500 / 4,000

    ▶Vertical (mm)　　　 600 / 800 / 900 / 1,000 / 1,300 / 1,600 / 1,800 / 2,000 / 2,500
    　　　　　　　　　　 (Non-Telescopic arm, Telescopic arm)

    ▶Driving method 　　All axes AC Servo

    ▶Payload (Kg) 　　　 3 / 5 / 10 / 15 / 20 / 25 / 35 / 50 (Including weight of chuck unit)

    ▶Power source　　　 AC 220V, 50/60 Hz

Drawing
General specification
Dimensions
Purchase consultation

FRANCIA series

Content
View Content
